• Ideal for mass production assembly and maintenance fields. • Limit switch version (QSPCAMS) applies for torque verification (Pokayoke) processes.
• Cam Action Mechanism Tohnichifs original cam-link mechanism generates a 45 degree gsliph action. Once torque set is achieved, even if more force is applied, the tool does not add additional torque. • 100K Cycles of Accuracy Stability Superior durable accuracy; 100,000 tightening cycles or one year. By measuring and adjusting each 100,000 cycles, it will be possible to use for up to 1,000,000 cycles. • No Torque Variation by Gripping Point Designed so that gripping point has no affect on the torque, individual tightening variations between beginners and skilled operators are reduced. • Ratchet Structure 36 teeth ratchet gear allows for 10 degree of operation in tight spaces. • ESD Standard Approved Conforms to the Electrostatic Discharge (ESD) standard; IEC 61340-5-1:2007 • Quick Torque Adjustment by Hex Key The set torque cannot be changed without using a special hex key (No.931), preventing the operator from changing torque by mistake. • Error-Proofing (Pokayoke) System with Limit Switch Version. • Upon reaching the set torque, the limit switch version (QSMCAMS) sends out a contact signal simultaneously, which can be connected to CNA-4mk2 (count checker) or PLC to create tightening count management system. • QSPCA30N, QSPCA70N and their LS version added to the line-up (2011.09.21-)
